Dimensions (HxWxD)

Product Dimensions (HxWxD)

36 3/8" x 35 1/2" x 26 5/8"

Product Features


Includes a rear fan to distribute hot air throughout the oven for faster, more even baking
Fan convection

Includes a rear fan to distribute hot air throughout the oven for faster, more even baking

Delivers intense heat for high-output cooking performance
Triple-Ring Burner with Wok Ring Included

Delivers intense heat for high-output cooking performance

See your cooking skills in action. Halogen lights spread bright, clear light throughout the oven for easy viewing.
Halogen lights

See your cooking skills in action. Halogen lights spread bright, clear light throughout the oven for easy viewing.

Additional Features

Heavy-duty continuous cast-iron grates

Go with your culinary flow. Continuous grates allow for easy movement of cookware while providing even heat distribution with better heat retention.

Sealed burners

When your culinary creativity overflows, no worries. Sealed burners contain spills for quick and easy clean up, while also protecting the burners.

Stainless Steel Sides
Three Cooking Modes
Broil Pan Set, Conversion Kit and Backguard Included

Specs & Details


Capacity

    • Total Capacity (cubic feet)
    • 3.8 cu ft

Features

    • Configuration
    • Single Oven
    • Oven Features
    • Clock/Timer
    • Ignition System
    • Electronic
    • Burner - Right Rear
    • 6,900 BTU
    • Interior Oven Light
    • 2
    • Fuel Type
    • Natural Gas (factory set)
    • Oven Interior
    • Black
    • Oven Control Features
    • In-Oven Broiling
    • Oven Cooking Modes
    • Bake, Broil, Convection Bake
    • Cooktop Burner Type
    • Sealed
    • Oven Rack Features
    • 2 Racks, Shallow Baking Pan Included
    • Burner - Left Rear
    • 6,900 BTU
    • Oven Cleaning Type
    • Manual
    • Cooktop Type
    • Continuous Grates
    • Cooktop Burner Grate Material
    • Heavy Duty Cast Iron
    • Cooktop Burner Grate Features
    • Continuous Grates
    • Burner - Center
    • 17,400 BTU
    • Burner - Right Front
    • 5,000 BTU
    • Cooktop Surface
    • Deep Recessed
    • Burner - Left Front
    • 8,200 BTU
    • Control Location
    • Front
    • Tri-Ring Burner
    • Yes
    • Number of Convection Oven Fans
    • 1
    • Dishwasher Safe Knobs
    • Yes
    • Leveling System
    • 4 Leveling Legs
    • Control Type
    • Heavy Duty Knob
    • Cooking Technology
    • Fan Convection

Claims & Certifications

    • ADA Compliant
    • Yes
    • CSA
    • Yes
    • California Prop 65
    • Yes

Appearance

    • Cooktop Burner Grate Color
    • Matte Black
    • Oven Door Features
    • Oven Window
    • Handle
    • Stainless
    • Control Knobs
    • Metallic
    • Door Swing
    • Pull Down
    • Color Appearance
    • Stainless

Weights & Dimensions

    • Net Weight
    • 182.0 lb
    • Oven Interior Dimensions (W x H x D) (in.)
    • 27-1/8 x 14 x 17
    • Height to Cooking Surface (in.)
    • 36
    • Depth with Door Open
    • 42.5 in
    • Cabinet Width
    • 35.5 in
    • Approximate Shipping Weight
    • 205.0 lb
    • Overall Width
    • 35.500000 in
    • Overall Depth
    • 26.625 in
    • Overall Height
    • 36.375 in

Power / Ratings

    • Top Burner BTU Rating - Nat. Gas (000's BTU's)
    • (1) 17.4; (1) 8.2; (2) 6.9; (1) 5.0
    • Electrical Requirements
    • 120V, 60Hz
    • Top Burner BTU Rating - LP (000's BTU's)
    • (1) 15.0; (2) 6.5; (1) 8.3; (1) 5.0
    • Amp Rating at 240V
    • 0.8
    • Bake/Broiler BTU Rating - Nat. Gas (000's BTU's)
    • 14.2/9.3
    • Bake/Broiler BTU Rating - LP (000's BTU's)
    • 13.9/9.2

Warranty

    • Labor Warranty
    • 1 Year
    • Parts Warranty
    • 1 year
    • Warranty Notes
    • See written warranty for full details

Accessories

    • Cooking Tray
    • Included
    • LP Conversion Kit
    • Included
    • Wok Accessory
    • Included
    • Optional Backguard
    • Included
